Springfield Echelon Performance Compensator
- Designed around the OEM threaded barrel that is available on Springfields website.
- Runs with OEM recoil spring and 115gr ammunition.
- Adds 1.175" from face of slide, and is the shortest OEM barrel compatible Echelon Compensator on the market.
- Extends .675" past a Streamlight TLR1.
- Extends .250" past a Surefire X300.
- Single top port with side ports.
- Designed to flow nicely with the OEM slide design, while also standing out on its own.
- Easy install.
- Like any of our designs, Performance drives everything.
- Type III hard coat anodized black.
- Comes with all necessary hardware.
INSTALLATION INSTRUCTIONS
- REMOVE MAGAZINE AND ENSURE PISTOL IS CLEAR AND SAFE.
- REMOVE SLIDE FROM FRAME.
- REMOVE RECOIL SPRING AND BARREL.
- MAKE SURE BARREL THREADS ARE CLEAN AND FREE OF DEBRIS.
- INSTALL THREADED BARREL INTO SLIDE.
- PUSH BARREL OUT OF BATTERY TO WHERE IT IS PROTRUDING FROM FRONT OF SLIDE.
- APPLY BLUE LOCTITE 243 TO BARREL THREADS.
- SCREW ON COMPENSATOR ALL OF THE WAY AND STRAIGHTEN TO MATCH SLIDE.
- PUSH BARREL INTO BATTERY.
- REMOVE BARREL FROM BATTERY AND UNSCREW COMP 1 ROTATION AT A TIME UNTIL BARREL GOES INTO BATTERY.
- STRAIGHTEN COMP TO MATCH SLIDE.
- APPLY BLUE LOCTITE 243 TO SET SCREWS AND INSTALL SCREWS IN COMP WITH A 1/16 ALLEN WRENCH.
- TIGHTEN SET SCREWS ONTO BARREL OD.
- YOU MAY HAVE TO GO BACK AND FORTH BETWEEN SET SCREWS FOR STRAIGHTNESS.
- LET LOCTITE CURE FOR 24 HOURS.
- CLEAN COMP EVERY 750-1000 ROUNDS.
